subtractive manufacturing
A conventional process of manufacturing by removing material from bulk to form the net shape.
Epilog fusion m2 40
Dual source fiber and CO2 laser cutter and engraver.
Hardware:
Working volume: 40" x 28" x 13.25"
Resolution: user controlled from 75 to 1200 DPI
Variable laser speed and power
Rotisserie attachment available for rotational engraving
75W CO2 laser
50W fiber laser
Software:
LittleMachineShop 5500 Bench Mill
Powerful metalworking bench mill.
Hardware
750 watt (1 hp) brushless DC variable speed drive
No gears in spindle drive
R8 spindle and drill chuck
Tapping mode for reversing taps out
23.4" x 5.5" table
Accurate to 0.0004"
LittleMachineshop 3540 bench lathe
Powerful metalworking bench lathe.
Hardware
8.5" swing over the bed
1000 Watt (1.34 HP) brushless DC drive
Power longitudinal feed and power cross feed
4" 3-jaw self centering lathe chuck
Dual grit 6" bench grinder.
Hardware
6" wheel diameter
36 and 60 grit wheels
Built in eye shields, spark deflectors, and tool rests
Motor runs at 3,450 rpm with no load
12-1/2" distance between wheels
5/8 HP induction motor
A combination belt sander and disc sander.
Hardware
6" disc diameter
4" x 36" belt
Belt tilts up to 90° for horizontal or vertical sanding
Miter gauge included for disc sander for sanding angled edges
Disc motor runs at 3450 rpm with no load
Belt runs at 1900 sfm with no load
1/2 HP motor
CARBIDE NOMAD 883
While the Carbide Shapeoko 3 has a large cutting area with a lot of power, the Nomad is built to take up minimal space and cut a wide variety of materials without making a mess.
Hardware
8” x 8” x 3” cutting area
Capable of cutting wood, plastic, and light aluminum
Fully enclosed CNC
Capable of small precise mills down to 1/32”
1/4” or 1/8” shank bits accepted
20" floor drill press with rotation and tilt.
Hardware
Quick adjustment motor mount for rapid changing of spindle speeds
Rotating, 45° tilting, crank operated worktable with release clamp
1/2" diameter external depth stop with three nut locking feature for quick adjustment
Drills to center of circle: 20"
Cast iron drilling capacity: 1"
Mild steel drilling capacity: 3/4"
Column to spindle distance: 10"
cARBIDE SHAPEOKO 3 CNC ROUTER
Shapeoko gives you higher precision, higher productivity, and the ability to take on projects that you can’t do any other way. You’ll be limited only by your imagination, not by your tools
16” x 16” x 3” cutting area
Capable of cutting wood, plastic, and light aluminum
Fully enclosed CNC
Capable of small precise mills down to 1/16”
1/4” or 1/8” shank bits accepted
